Description

The Tetra Pak Inline Blender D (2021) is a state-of-the-art blending solution designed for high-capacity liquid processing applications. This system delivers precise ingredient blending with automated control, high shear mixing, and optimized pressure conditions to ensure consistent product quality.

The unit is fully pre-assembled, including flow and temperature transmitters, control valves, a 6,000L buffer tank, an inline high shear mixer, and a centrifugal pump, allowing for seamless integration into existing processing lines.

Equipped with a stainless-steel control panel, Siemens PLC, and Wonderware InTouch HMI interface, this blender enables intuitive operation, remote monitoring, and real-time process control. The system is designed to be highly hygienic, making it ideal for dairy, beverage, and food processing applications.

Key Features:
✅ High-capacity inline blending: Up to 26,500 LPH
✅ Advanced automation: Siemens PLC with HMI interface & remote operation capability
✅ High-efficiency mixing: 37 kW inline high shear dynamic mixer
✅ Pre-assembled for seamless integration: All internal wiring, piping, and MCC panel included
✅ Hygienic design: Stainless steel construction with air-cooled control unit
✅ Precise ingredient control: Flow & temperature transmitters, sampling valves, and non-return valves

Technical Specifications:
Make: Tetra Pak
Model: Inline Blender D
Year: 2021
Capacity:
Unit 4: 26,500 LPH
Unit 2 & 3: 20,000 LPH
Pressure Conditions: Ingredient pressure must be 100 – 500 kPa higher than the blending point pressure
Final Product Density: 1,050 kg/m³
Ingredient Temperature: 4 – 30°C
Availability: Immediate
